Howo 6x4 Crane Truck

The HOWO 6x4 Crane Truck is a heavy-duty vehicle integrating cargo transport and hydraulic lifting functions, suitable for construction projects, logistics operations, infrastructure maintenance, mining applications, and industrial cargo handling.





Technical Parameters



Specification	Details
Model	HOWO 6X4 Crane Truck
Drive Type	6x4
Engine	Sinotruk WD615.47, 371 HP, 9.726L, Turbocharged Diesel, Euro V Emission Standard
Transmission	10-speed manual transmission for smooth operation and efficient power distribution
Front Axle	7.5-ton front axle for stability and superior load distribution
Rear Axle	16-ton rear axle with a 5.73 gear ratio for optimal performance
Suspension System	Multi-leaf spring suspension with shock absorbers for improved comfort and durability
Braking System	Drum brakes with ABS (Anti-lock Braking System) and auxiliary engine brake
Crane Model	6-ton or 8-ton hydraulic crane with advanced lifting features and safety mechanisms
Crane Reach	Maximum lifting height of 20 meters with a reach of up to 16 meters
Cabin	Spacious cabin with air-suspended driver's seat, ergonomic design, and climate control
Seats	Adjustable air-suspended seat for driver comfort
Safety Features	ABS, Electronic Stability Control (ESC), Hill Start Assist, and the Crane overload protection system
Fuel Tank Capacity	400L
Gross Vehicle Weight	30,000 kg
Dimensions (L × W × H)	10,800 mm × 2,550 mm × 3,750 mm
Wheelbase	1,850 + 3,700 mm



Key Features



· HOWO 6x4 heavy-duty chassis for truck-mounted crane applications with reinforced frame and dual rear axle configuration.

· Multi-section telescopic boom with hydraulic lifting and 360° rotation system for truck crane operations.

· Manual transmission system matched with heavy-load transport applications.

· Left-hand drive and right-hand drive chassis configurations available.

· Hydraulic stabilizer system installed for lifting balance and operational support.

· 400L fuel tank for extended working range in construction crane truck applications.

· Euro V emission standard configuration for international heavy-duty crane truck compliance.

Manufacturing & Quality Control



Each HOWO 6x4 crane truck is produced under a standardized manufacturing system.

• Chassis structural inspection is carried out during assembly.
• Hydraulic system pressure testing is completed before installation.
• Crane load testing is performed before final assembly.
• Welding joints are inspected for structural integrity.
• Electrical systems are verified before delivery.
• Road testing is conducted on finished units.
• Final inspection is completed before shipment.

Shipping & Transportation



1. Each HOWO 6x4 crane truck is secured with transport protection before shipment.

2. Crane and chassis components are fixed for stability during ocean transport.

3. Hydraulic systems are locked and pressure-stabilized before loading.

4. The unit is shipped via Ro-Ro vessel, flat rack container, or bulk vessel.

5. Wheel chocks and frame locking systems are applied during loading and transport.

6. External components are protected with export-grade covering materials.

7. Standard export documents are provided with each shipment: Commercial Invoice, Packing List, Bill of Lading, Certificate of Origin.



FAQ



Q1: Can this truck handle continuous heavy lifting work every day?

A: Yes. The HOWO chassis and hydraulic crane are both designed for heavy-duty, frequent use. As long as you follow the maintenance schedule, it can handle daily lifting tasks reliably.

Q2: How long does it take to get spare parts if something breaks down overseas?

A: Most common parts can be shipped to your location within 7–15 working days. We also keep key parts in stock for urgent orders.

Q3: Is it easy for my team to learn how to operate the crane?

A: Yes. The crane has intuitive controls, and we provide multi-language operation manuals and video guides. Our technical team can also walk your staff through basic operation and maintenance via remote support.

Q4: Can I use this truck in extreme weather or remote areas?

A: The truck is built to handle high temperatures, dusty conditions, and rough roads common in many overseas projects. We can also recommend optional upgrades like additional air filtration or heavy-duty cooling systems if needed.

Q5: Do you offer a warranty on the crane and chassis?

A: Yes. We provide a standard warranty period for both the chassis and the crane. The exact terms depend on the configuration and your location - our sales team will share the full warranty details with you before you order.
